Introduction

This case study has been divided into three (3) components.

You are to design a network, research and source appropriate devices justifying choices (feasibility, efficiency, etc.), subnet the network, assign IP addresses to the appropriate devices, and design ACLs to satisfy security requirements.

Deliverables

1.   A single Word document (.docx) – containing all parts

Assignment breakdown

Scenario

myNetwork Services Inc., a Singapore data analytics company, has asked you to assess and redesign   their network. They are opening several branches in several cities around the world, which will require new equipment. They have existing contracts and hardware to maintain fibre-optic leased line WAN    links between sites.

PART 1 - Network diagram

PART 2 - Subnet the network and assign IP addresses to the appropriate devices

PART 3 - Research and source appropriate devices justifying choices (feasibility, efficiency, etc.) with a Weighted Scoring Model (WSM)

PART 1 - Network specifications and diagram

Network Specifications

You have been given a rough sketch of the network topology below. You are to draw the network using draw.io, subnet the network (see part 2), and assign port numbers and IP addresses to ports.

Network Structure

Hardware

•   Only include one switch in your diagram for each LAN or WLAN (even if more are required)

•   Servers should be on their own LAN

•   The Singapore router is connected to the Internet and provides access to the public backbone containing a web server, a mail server, and a database server.

•   The Taipei router provides access to a mail server.

PART 2 - Subnet the network using VLSM, and assign IP addresses to the appropriate devices.

Each location has the following number of hosts

Subnetting

Use VLSM to subnet the network topology using a public class B network. You are to use the table format below to provide the subnet details.

Table 1. Subnets (including WAN subnets)

Spreadsheet Columns:  Subnet name, subnet address, subnet mask (in slash format), first useable address, last useable address, broadcast address, static address range and DHCP address range (all addresses to be in dotted decimal notation)

Table 2. Router Interfaces

Spreadsheet Columns:  Location, interface, IP address, subnet mask (in slash format) Table 3. Servers

Spreadsheet Columns:  Location, server name, IP address, subnet mask (in slash format)

Additional requirements:

•   Choose one public B class network address for the entire network and subnet this block of addresses to optimise spare addresses for future expansion.

•   Place the WAN subnets in the blocks directly following the LAN/WLAN address space.

•   Add 100% to each subnet to allow for growth in the number of hosts specified for each LAN

(i.e. workstations × 2). Do not allow for any growth in the number of servers or size of WLANs

•   DHCP will to be used for IP address allocation for hosts in each subnet and these ranges are to be allocated for each LAN.

•   Static IP addresses are to be allocated where appropriate: router interfaces and servers.

•   The ISP has given us an IP address of 100.200.16.26/30 for our Internet connection at Perth

Note: this address is part of the ISP’s network, and is not involved in subnetting for the corporate network.

PART 3 - Research and source appropriate devices justifying choices (feasibility, efficiency, etc.)

You are to research and submit a project procurement plan for the Singapore network. The devices you must include are routers, switches, and wireless access points. Make sure the devices you select can handle the number of workstations required and provide a good quality of service to wired and wireless users. Devices should be enterprise-grade, not home or gaming equipment.

Your project plan and final recommendations should be based on a Weighted Decision Matrix (like the WDM you did in the Procurement Practical). You are to compare four (4) devices from each category  and to base the decision on reasonable and well-justified attributes.

The budget for procurement is $4,000. You may exceed this if you can justify it well.

Your project plan is to contain the following components:

Weighted Decision Matrix - hardware resource requirements analysis

•   Include a written justification for priorities and attributes given in the matrix

•   Create your WDMs in Excel and copy and paste them into your Word doc

Budget

•   Create a well-presented table of the prices of all devices and the total cost

•   Include hardware only, not labour
